MC cable UL listed 1569 metal clad cable Type metal cable 600volts power cable copper conductor ALuminum Armor/thhn/thwn-2

Short Description:


  • Min.Order Quantity: 10000 Feet/Feet
  • Supply Ability: 10,000,000 Feet/Feet per Month
  • Port: Qingdao
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    Product Tags

    Product Description



    Type MC

    14 AWG through 1000kcmil Copper THHN/THWN-2 Insulated Singles. UL Listed. 600 Volts. Rated VW-1. Lightweight Aluminum Interlocked Armor.

    Scope

    This specification covers lightweight aluminum interlock armor type MC cable with soft annealed copper solid or stranded conductor,THHN/THWN insulated singles, conforming to Standard 1569 of Underwriters Laboratories, Inc. UL file No.E313205 .

    Application

    Type MC cables are suitable for use as follows: branch, feeder and service power distribution in commercial, industrial, institutional, and multi-residential buildings. Power, lighting, control, and signal circuits. Type THHN/THWN conductors are rated 90℃ dry / 75℃ wet. They are permitted for 600V application.

    Conductors: Soft annealed copper .

    Sizes:14AWG-1000kcmil. .

    Insulation: Flame retardant PVC.  Thickness: per UL83.

    Color coding:

    Number of conductors

    Color

    2

    3

    4

    Grounding conductor

    black, white

    black, white, red

    black, white, red, blue

    green

    Conductor jacket: Nylon. Thickness: per UL83.

    Cabling: Three or more conductors are assembled without fillers and wraped by a polyester binder tape. A marker tape is inserted under the binder tape.

    Armor: Aluminum interlock armor is applied over the assembly.

    Jacket: A flame retardant PVC jacket is optional.

    Information  on  the  marker tape or the jacket:  AWG or kcmil size,conductor type letters,rated voltage,the name of the manufacturer,UL file number,characteristic,manufacture date,FEET.

      Type MC Cable Data

    _20181228222813

    Packaging Information: Coils or Reel

    Certifications

     MC UL.JPG

    Packaging

    MC cable.JPG

    Our Factory
    .jpg
    FAQ

    (1) When can I get a response?

    We will reply to your inquiry as soon as possible, usually within 6 hours. You can call us directly if it is urgent.

    (2). How can I get a sample?

    you can require for samples after price confirmation. Samples in stock are free of charge, but the freight charge should be paid.

    (3). What about the lead time for mass production?

    It depends on the order quantity, the distance of transportation and so on. We suggest that you start inquiry two months before the date you would like to get the products at your country.



    Please contact us for details about lead time and other issues.

    We look forward to sincere cooperation with you!
